Water ring roots  Vacuum Pump Units

Water ring roots Vacuum Pump Units

- Water ring roots Vacuum Pump Units

水环罗茨机组图片1
水环罗茨机组图片2
水环罗茨机组图片3
水环罗茨机组图片1 水环罗茨机组图片2 水环罗茨机组图片3
High efficiency, compact structure, no leakage, corrosion resistance, high protection level! The water ring Roots unit is composed of a Roots pump as the main pump, a 2BV/2BE1 series water ring pump or a Roots-Water ring unit as the pumping unit of the foreline pump. In addition to being used to remove general gases, it can also pump gases containing moisture, organic solvents or small amounts of dust. Compared with general mechanical vacuum pumps, it is not afraid of oil pollution, and is not afraid of water vapor and fine dust. Compared with general water ring vacuum pumps, it has the characteristics of high vacuum and high pumping speed under high vacuum conditions.
Characteristics

Water ring Roots unit structure features

1.Thanks to the energy efficient 2BV/2BE1/2BE1S seriesWater ring pumpUsed as a foreline pump, it has the advantages of high efficiency, compact structure, no leakage, corrosion resistance and high protection level.Roots water ring vacuum unitThe working fluid of the foreline pump is mostly water, organic solvent (organic solvent such as methanol, ethanol, xylene, acetone, etc.) or other liquid can be used, and the foreline pump is used as a closed loop system, which greatly reduces the environment. The pollution, while greatly improving the recovery of organic solvents. The ultimate vacuum is determined by the saturated vapor pressure of the working fluid.

2.In addition to being used to remove general gases, it can also pump gases containing moisture, organic solvents or small amounts of dust. Compared with general mechanical vacuum pumps, it is not afraid of oil pollution, and is not afraid of water vapor and fine dust. Compared with general water ring vacuum pumps, it has the characteristics of high vacuum and high pumping speed under high vacuum conditions.

Water ring Roots unit equipment

Liquid ring roots unit The main components include: Liquid ring vacuum pump/compressor, Roots pump,Control cabinet, shared chassis, internal pipeline

Different configurations, different technical performances, and different effects. The vacuum unit has two, three, four-stage vacuum units, all levels of Roots vacuum pump and liquid ring vacuum pump to form the technical performance of the vacuum unit. Due to different requirements and different conditions, we can recommend according to different process of customers. Select the vacuum unit that suits the requirements. Please contact our sales technical department to provide a solution.

Water ring Roots unit flow chart

typical application

Roots screw vacuum pump unit Typical applications: chemical and pharmaceutical, semiconductor, solvent recovery, molding, crystallization, dry etching, sputtering, steam recovery, high-altitude simulation
